Air Conditioner Four Way Reversing Valve For Heat Pump Refrigeration

Brand Name : BRANDO

Model Number : 4TB-20

Certification : CE, ISO

Place of Origin : Ningbo, China

MOQ : 500pcs

Price : Negotiation

Payment Terms : T/T, Paypal, Western Union

Supply Ability : 50000pcs per month

Delivery Time : 20 to 30 working days

Packaging Details : Box, Carton, Pallet

Product Name : 4 Way Reversing Valve

D Port Size : 12.8mm (1/2'')

E.S.C Port Size : 19.2mm (3/4'')

Power : 4 to 8HP

Applicable Refrigerant : R22, R407C, R410A, etc

Application : Heat Pump, Air Conditioning, etc

Voltage : 24VDC, 24VAC, 110VAC, 220VAC

Contact Now

Air Conditioner Four Way Reversing Valve For Heat Pump Refrigeration

The 4-way valves are used in reversible applications such as heat pumps or reversible air conditioning units and chillers.
The 4-way valve allows an inversion of the refrigeration cycle, changing from cooling mode in summer to heating mode in winter.
The 4-way valve slider is shifted by changes in differential pressure in the valve which is actuated by the pilot solenoid valve. The valve slider is specially designed to prevent incomplete changeover and movement with minimum pressure differential.

Technical Data:

Air Conditioner Four Way Reversing Valve For Heat Pump Refrigeration
Model No
Orifice Size
(mm)
Port Size
(mm)
Operating Pressure Difference (MPa)
Internal Leakage (ml/min)
P=1MPa at 70℃
Power
(HP)
D
E.S.C
Min
Max
4TB-4U
8
8.1
9.6
0.25
2.5
＜1000
0.75 to 1.5
4TB-9U
11
9.6
12.8
0.34
2.25
＜1500
2 to 3
4TB-11
11.5
12.8
16
0.34
2.25
＜2000
2.5 to 4
4TB-11U
11.5
9.6
16
0.34
2.25
＜2000
2.5 to 4
4TB-20
13
12.8
19.2
0.34
2.25
＜4000
4 to 8
4TB-20U
13
12.8
19.2
0.34
2.25
＜4000
4 to 8
4TB-34
20
19.05
22.2
0.34
2.25
＜6000
7.5 to 12
4TB-45
23
22.2
28.5
0.34
2.76
＜6000
5 to 15
25.6
28.5
34.9
0.34
2.76
＜6000
5 to 20

Working Principle:

Air Conditioner Four Way Reversing Valve For Heat Pump Refrigeration

Structure:

Air Conditioner Four Way Reversing Valve For Heat Pump Refrigeration

Our Production:
Air Conditioner Four Way Reversing Valve For Heat Pump Refrigeration
