Normally Open Electric Steam Solenoid Valve 3/8'' 1/2'' 3/4'' 1'' 24VDC 220VAC

Brand Name : Brando

Model Number : 16CB-S

Certification : CE

Place of Origin : China

MOQ : 1 pc

Price : Negotiation

Payment Terms : L/C, T/T, PayPal, Western Union, MoneyGram

Supply Ability : 100000 pcs per month

Delivery Time : 4-8 days

Packaging Details : Inner boxes, Carton, Pallet

Port Size : 3/8'', 1/2'', 3/4'', 1'', 1 1/4'', 1 1/2'', 2''

Orifice Size : 12mm, 15mm, 20mm, 25mm, 32mm, 40mm, 50mm

Operation Mode : 2 Way Normally Open

Operation : Piston Pilot Operated

Body Material : Stainless Steel 304

Seal Material : PTFE, FKM

Working Medium : Steam, Hot Water, High Temp Liquid, Oil, etc

Voltages : 12VDC, 24VDC, 24VAC, 110VAC, 220VAC

Pressure Range : 0.05 to 1.6 MPa

Temperature Range : 0 to +180℃

Contact Now

Normally Open Electric Steam Solenoid Valve 3/8'' 1/2'' 3/4'' 1'' 24VDC 220VAC


Product Features of Steam Solenoid Valve:

1. Working Medium: Hot Water, Steam, Oil, etc
2. Working Pressure Range: 0.5 to 16 Bar
3. Seal Material: PTFE, FKM
4. Body Material: Brass, Stainless Steel
5. Port Size: 3/8'', 1/2'', 3/4'', 1'', 1 1/4'', 1 1/2'', 2''
6. Orifice Size: 12mm, 15mm, 20mm, 25mm, 32mm, 40mm, 50mm
7. Operation: Piston Pilot Operated
8. Coil Voltage Option: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)

Technical Data of Steam Solenoid Valve:

Model
Port Size
Orifice Size
Cv
Min Pressure
Max Pressure
Seal Material
Body Material
AC
DC
Normally Closed
16CA12
3/8''
12mm
4.5
0.05MPa
1.6MPa
1.6MPa
PTFE
FKM
Brass
Stainless Steel
16CA15
1/2''
15mm
4.5
16CA20
3/4''
20mm
9.3
16CA25
1''
25mm
12
16CA32
1 1/4''
32mm
24
16CA40
1 1/2''
40mm
29
16CA50
2''
50mm
48
Normally Open
16CB12
3/8''
12mm
4.5
0.05MPa
1.6MPa
1.6MPa
PTFE
FKM
Brass
Stainless Steel
16CB15
1/2''
15mm
4.5
16CB20
3/4''
20mm
9.3
16CB25
1''
25mm
12
16CB32
1 1/4''
32mm
24
16CB40
1 1/2''
40mm
29
16CB50
2''
50mm
48

Main Dimension of Steam Solenoid Valve:

Normally Open Electric Steam Solenoid Valve 3/8'' 1/2'' 3/4'' 1'' 24VDC 220VAC Normally Open Electric Steam Solenoid Valve 3/8'' 1/2'' 3/4'' 1'' 24VDC 220VAC

Orifice Size
A
B
C
DN12
73
48
113
DN15
73
48
113
DN20
83
60
125
DN25
100
72
138
DN32
130
96
140
DN40
130
96
140
DN50
155
122
149
